Asus VivoBook 2023 Repair and Data Recovery
Asus released 24 VivoBook models in 2023: T3304, M1402, X1404, X1405 and 20 more. Two earlier models kept their numbers and changed inside. We repair them at component level and recover data from them, in London or by insured courier from anywhere in the UK.
VivoBook models released in 2023
The model number is on the label underneath the laptop, after the word MODEL. The letters that follow it, such as X1504ZA, identify the exact version.
| Model | Number | Screen | Processor |
|---|---|---|---|
| VivoBook 13 Slate OLED | T3304 | 13.3-inch OLED | Intel Core i3-N200 / N-series |
| VivoBook 14 | M1402 | 14-inch | AMD Ryzen |
| VivoBook 14 | X1404 | 14-inch IPS | Intel 12th/13th gen Core U, later Core 3 100U / Core 7 150U |
| VivoBook 14 | X1405 | 14-inch | Intel 12th or 13th gen Core |
| VivoBook 14X OLED | K3405 | 14-inch OLED or IPS | Intel 13th gen Core H (some 12th gen) |
| VivoBook 15 | M1502 | 15.6-inch | AMD Ryzen |
| VivoBook 15 | M1505 | 15.6-inch OLED | AMD Ryzen 7000U (Ryzen 5 7530U / Ryzen 7 7730U) |
| VivoBook 15 | X1504 | 15.6-inch IPS | Intel 12th/13th gen Core U, later Core 3 100U / Core 5 120U / Core 7 150U |
| VivoBook 15 | X1505 | 15.6-inch | Intel 12th or 13th gen Core |
| VivoBook 15X OLED | K3504 | 15.6-inch OLED | Intel 13th gen Core (i7-1360P / i7-1355U) |
| VivoBook 15X OLED | M3504 | 15.6-inch OLED | AMD Ryzen 7000U (Ryzen 7 7730U) |
| VivoBook 16 | M1605 | 16-inch | AMD Ryzen 7000U |
| VivoBook 16 | X1605 | 16-inch | Intel 12th or 13th gen Core |
| VivoBook 16X | K3605 | 16-inch OLED or IPS | Intel 12th/13th gen Core H |
| VivoBook 16X OLED | K3604 | 16-inch OLED | Intel 13th gen Core P (i7-1360P) |
| VivoBook 17 | X1704 | 17.3-inch IPS | Intel 13th gen Core U (later Core 5 120U / Core 7 150U) |
| VivoBook 17X | K3704 | 17.3-inch IPS | Intel 13th gen Core H |
| VivoBook 17X | M3704 | 17.3-inch IPS | AMD Ryzen 7000U (Ryzen 5 7530U / Ryzen 7 7730U) |
| VivoBook Go 14 | E1404 | 14-inch IPS | AMD Ryzen 7020U (E1404F) or Intel Core i3-N305 / N-series (E1404G) |
| VivoBook Go 15 | E1504 | 15.6-inch OLED or IPS | AMD Ryzen 3 7320U / Ryzen 5 7520U (E1504F) or Intel Core i3-N305 (E1504G) |
| VivoBook Pro 16X OLED | K6604 | 16-inch OLED | Intel 13th gen Core HX (i9-13980HX) |
| VivoBook S 14 OLED | K5404 | 14.5-inch OLED | Intel 13th gen Core H |
| VivoBook S 15 OLED | K5504 | 15.6-inch OLED | Intel 13th gen Core H |
| VivoBook S 16 Flip OLED | TP3604 | 16-inch OLED | Intel 13th gen Core H |
Earlier models updated in 2023
These kept the model number they launched with. The parts inside changed, so the full model number on the label matters when we order parts.
| Model | Number | What changed in 2023 |
|---|---|---|
| VivoBook Pro 16 | K6602 | Intel 13th gen Core processors |
| VivoBook Pro 15 OLED | K6502 | Intel 13th gen Core processors |
What is inside a 2023 VivoBook
- CPU platforms: Intel 13th gen (U-series i3-1315U / i5-1335U / i7-1355U in X1404 / X1504 / X1704, P-series i7-1360P, H-series up to i9-13900H in the 14X/16X/17X and S models), with 12th gen still sold in some variants; AMD Ryzen 7000U (7530U / 7730U) in M1505, M3504 and M3704.
- VivoBook Go 14 E1404 / Go 15 E1504 use AMD Ryzen 3 7320U / Ryzen 5 7520U (F variants) or Intel Core i3-N305 / N-series (G variants); the Go 15 is also sold with an OLED panel. The 13 Slate OLED T3304 uses an Intel Core i3-N200.
- VivoBook 14 X1404 / 15 X1504 / 17 X1704: typically 8GB soldered plus one SO-DIMM slot (some variants are onboard-only or SO-DIMM-only) and one M.2 2280 NVMe slot.
- Charging changed mid-generation: earlier variants (for example X1404VA) use a 45W 4.5mm barrel plug, later ones (for example X1404VAPBF, X1504VAP) charge over USB-C at 45-48W. The VivoBook 15 OLED M1505 uses a 45W 4.5mm barrel plug.
- VivoBook 14X OLED K3405: 8GB soldered plus one SO-DIMM slot and one M.2 slot, sold with IPS or 2.8K OLED panels. The 17-inch X1704 is listed with an IPS-level Full HD panel, with a 1600x900 TN panel on some base configurations.
Repairs we carry out on 2023 VivoBook laptops
- Screen replacement
- Charging port and power faults
- Keyboard replacement
- Hinge repairs, a common fault on these
- Motherboard repair
- SSD and memory upgrades
Where memory, storage or charging parts are soldered to the board, a fault there is a board-level repair, not a part swap. That is the work we do. See every year on the VivoBook page.
Data recovery from a 2023 VivoBook
When one of these laptops will not start, the files are usually still there. Most VivoBooks store everything on an M.2 NVMe SSD, which we can take out and read directly when the laptop has failed. Budget E-series and Go models may instead have eMMC storage soldered to the board; with those, the data can only be reached by working on the board itself.
Windows 11 switches on device encryption on many of these laptops without asking. If the drive is encrypted we need the BitLocker recovery key, which is normally saved in your Microsoft account.
| Initial consultation | Free |
| Deleted files on a standard hard drive | £99 + VAT |
| Logical recovery, 1TB to 4TB | £150 to £250 + VAT |
| Physical recovery, single drive | £450 + VAT |
| SSD recovery | £450 to £650 + VAT |
We start with a free consultation and give you a price before any recovery starts. See data recovery and the full price list.
Questions
Do you repair 2023 VivoBook laptops outside London?
Yes. We collect by insured courier from anywhere in the UK and send the laptop back the same way.
My VivoBook is not in the 2023 list. Can you repair it?
Almost certainly. The tables cover the models we see most. Call 020 7394 2521 with the model number from the label underneath.
Can you recover my files if the laptop will not turn on?
In most cases, yes. On most VivoBooks the SSD can be removed and read directly. On E-series and Go models with soldered storage, the board has to be worked on first. The first look is free.
Get a quote
Tell us the model and what is wrong, and we reply with a quote. Bring the laptop to our London workshop at 80 Willow Walk, Unit 1, London SE1 5SY, or have it collected by insured courier from anywhere in the UK. Nothing is done until you have agreed the price.
