Asus VivoBook 2024 Repair and Data Recovery
Asus released ten VivoBook models in 2024: TP3407, TP3607, N6506, M5406 and six more. Three earlier models kept their numbers and changed inside. We repair them at component level and recover data from them, in London or by insured courier from anywhere in the UK.
VivoBook models released in 2024
The model number is on the label underneath the laptop, after the word MODEL. The letters that follow it, such as X1504ZA, identify the exact version.
| Model | Number | Screen | Processor |
|---|---|---|---|
| VivoBook 14 Flip | TP3407 | 14-inch OLED | Intel Core Ultra Series 2 (Lunar Lake) |
| VivoBook 16 Flip | TP3607 | 16-inch OLED | Intel Core Ultra Series 2 (Lunar Lake) |
| VivoBook Pro 15 OLED | N6506 | 15.6-inch OLED | Intel Core Ultra 7 155H / Ultra 9 185H (Core Ultra 9 285H in 2025 refresh) |
| VivoBook S 14 OLED | M5406 | 14-inch OLED | AMD Ryzen 8000HS (Ryzen 9 8945HS), later Ryzen AI 300 |
| VivoBook S 14 OLED | S5406 | 14-inch OLED | Intel Core Ultra (Series 1) |
| VivoBook S 15 OLED | M5506 | 15.6-inch OLED | AMD Ryzen 8000HS, later Ryzen AI 300 |
| VivoBook S 15 OLED | S5506 | 15.6-inch OLED | Intel Core Ultra (Series 1) |
| VivoBook S 15 OLED | S5507 | 15.6-inch OLED | Qualcomm Snapdragon X Elite / X Plus |
| VivoBook S 16 OLED | M5606 | 16-inch OLED | AMD Ryzen 8000HS (Ryzen 9 8945HS), later Ryzen AI 300 |
| VivoBook S 16 OLED | S5606 | 16-inch OLED | Intel Core Ultra (Series 1; Core Ultra 9 285H on 2025 S5606CA) |
Earlier models updated in 2024
These kept the model number they launched with. The parts inside changed, so the full model number on the label matters when we order parts.
| Model | Number | What changed in 2024 |
|---|---|---|
| VivoBook 14 | X1404 | Intel Core 3 100U, Core 5 120U and Core 7 150U processors |
| VivoBook 15 | X1504 | Intel Core 3 100U, Core 5 120U and Core 7 150U processors |
| VivoBook 17 | X1704 | Intel Core 5 120U and Core 7 150U processors |
What is inside a 2024 VivoBook
- CPU platforms: Intel Core Ultra Series 1 (up to Ultra 9 185H) in the VivoBook S 14/15/16 OLED S5406 / S5506 / S5606 and Pro 15 OLED N6506; AMD Ryzen 9 8945HS and later Ryzen AI 300 in M5406 / M5506 / M5606; Core Ultra Series 2 (Lunar Lake) in the 14 Flip TP3407 / 16 Flip TP3607 from September 2024.
- VivoBook S 15 S5507 is the Snapdragon X Elite / X Plus model (ARM, Copilot+ PC): 16GB or 32GB LPDDR5X soldered, one M.2 2280 PCIe 4.0 slot (single-sided SSDs only), USB-C charging at 65W or 90W.
- VivoBook S 2024 models are OLED throughout (3K 120Hz; 16:10 on the 14 and 16, 16:9 on the 15.6) with up to 32GB LPDDR5X, a soldered memory type, up to 1TB PCIe 4.0 SSD and a 75Wh battery.
- VivoBook Pro 15 OLED N6506: 8GB DDR5 onboard plus one SO-DIMM slot (24GB maximum), two M.2 2280 PCIe 4.0 slots, RTX 4050, and a 200W barrel-plug charger.
- Mainstream VivoBook 14 X1404 / 15 X1504 carried on with Intel Core 3 100U / Core 5 120U / Core 7 150U.
Repairs we carry out on 2024 VivoBook laptops
- Screen replacement
- Charging port and power faults
- Keyboard replacement
- Hinge repairs, a common fault on these
- Motherboard repair
- SSD and memory upgrades
Where memory, storage or charging parts are soldered to the board, a fault there is a board-level repair, not a part swap. That is the work we do. See every year on the VivoBook page.
Data recovery from a 2024 VivoBook
When one of these laptops will not start, the files are usually still there. Most VivoBooks store everything on an M.2 NVMe SSD, which we can take out and read directly when the laptop has failed. Budget E-series and Go models may instead have eMMC storage soldered to the board; with those, the data can only be reached by working on the board itself.
Windows 11 switches on device encryption on many of these laptops without asking. If the drive is encrypted we need the BitLocker recovery key, which is normally saved in your Microsoft account.
| Initial consultation | Free |
| Deleted files on a standard hard drive | £99 + VAT |
| Logical recovery, 1TB to 4TB | £150 to £250 + VAT |
| Physical recovery, single drive | £450 + VAT |
| SSD recovery | £450 to £650 + VAT |
We start with a free consultation and give you a price before any recovery starts. See data recovery and the full price list.
Questions
Do you repair 2024 VivoBook laptops outside London?
Yes. We collect by insured courier from anywhere in the UK and send the laptop back the same way.
My VivoBook is not in the 2024 list. Can you repair it?
Almost certainly. The tables cover the models we see most. Call 020 7394 2521 with the model number from the label underneath.
Can you recover my files if the laptop will not turn on?
In most cases, yes. On most VivoBooks the SSD can be removed and read directly. On E-series and Go models with soldered storage, the board has to be worked on first. The first look is free.
Get a quote
Tell us the model and what is wrong, and we reply with a quote. Bring the laptop to our London workshop at 80 Willow Walk, Unit 1, London SE1 5SY, or have it collected by insured courier from anywhere in the UK. Nothing is done until you have agreed the price.
